Allen-Bradley 1734-OB8S User Manual

224 Rockwell Automation Publication 1734-UM013N-EN-P - September 2017
Appendix F I/O Assemblies
864 (360 h) 96 Input Type (Dual Channel Mode) 49 4 1
Safety Input 3 Configuration Data
97 Input Range 49 4 3
98 Input Channel Mode 49 4 4
99 Filter Setting 49 4
100 Input Error Latch Time (Low Byte) 49 4 8
101 Input Error Latch Time (High Byte) 49 4 8
102 Low Engineering (Low Byte) 49 4 14
103 Low Engineering (High Byte) 49 4 14
104 High Engineering (Low Byte) 49 4 15
105 High Engineering (High Byte) 49 4 15
106 Tach Dual Low Check 49 4 104
107 Tach Trigger 49 4 105
108 Tach OFF Level 49 4 106
109 Tach ON Level 49 4 107
110 Sensor Power Mode 49 4 103
111 High High/Low Low Alarm Enable 49 4 17
112 High High/Low Low Alarm Trip High (Low Byte) 49 4 18
113 High High/Low Low Alarm Trip High (High Byte) 49 4 18
114 High High/Low Low Alarm Trip Low Low(Low Byte) 49 4 19
115 High High/Low Low Alarm Trip Low Low(High Byte) 49 4 19
116 High High/Low Low Alarm Deadband (Low Byte) 49 4 20
117 High High/Low Low Deadband (High Byte) 49 4 20
118 Pad Byte (Reserved) 49 … …
119 High/Low Alarm Enable 49 4 22
120 High/Low Alarm Trip High (Low Byte) 49 4 23
121 High/Low Alarm Trip High (High Byte) 49 4 23
122 High/Low Alarm Trip Low (Low Byte) 49 4 24
123 High/Low Alarm Trip Low (High Byte) 49 4 24
124 High/Low Alarm Deadband (Low Byte) 49 4 25
125 High/Low Alarm Deadband High Byte) 49 4 25
126 Pad Byte 1 … … …
127 Pad Byte 2 … … …
864 (360 h) 128 Ch 0_1 Discrepancy Time (Low Byte) 4B 1 3
Dual Channel Safety Input 0_1
Configuration
129 Ch 0_1 Discrepancy Time (High Byte) 4B 1 3
130 Ch 0_1 Discrepancy Deadband (Low Byte) 4B 1 6
131 Ch 0_1 Discrepancy Deadband (High Byte) 4B 1 6
132 Ch 0_1 Channel Offset (Low Byte) 4B 1 100
133 Ch 0_1 Channel Offset (High Byte) 4B 1 100
134 Ch 2_3 Discrepancy Time (Low Byte) 4B 2 3
Dual Channel Safety Input 2_3
Configuration
135 Ch 2_3 Discrepancy Time (High Byte) 4B 2 3
136 Ch 2_3 Discrepancy Deadband (Low Byte) 4B 2 6
137 Ch 2_3 Discrepancy Deadband (High Byte) 4B 2 6
138 Ch 2_3 Channel Offset (Low Byte) 4B 2 100
139 Ch 2_3 Channel Offset (High Byte) 4B 2 100
Table 34 - Configuration Assemblies for 1734-IE4S Input Modules (continued)
Instance Decimal
(hex)
Byte Field Class
(hex)
Instance
(decimal)
Attribute
(decimal)
Description
