Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 223
I/O Assemblies Appendix F
864 (360 h) 64 Input Type (Dual Channel Mode) 4B 3 1
Safety Input 2 Configuration Data
65 Input Range 49 3 3
66 Input Channel Mode 49 3 4
67 Filter Setting 49 3
68 Input Error Latch Time (Low Byte) 49 3 8
69 Input Error Latch Time (High Byte) 49 3 8
70 Low Engineering (Low Byte) 49 3 14
71 Low Engineering (High Byte) 49 3 14
72 High Engineering (Low Byte) 49 3 15
73 High Engineering (High Byte) 49 3 15
74 Tach Dual Low Check 49 3 104
75 Tach Trigger 49 3 105
76 Tach OFF Level 49 3 106
77 Tach ON Level 49 3 107
78 Sensor Power Mode 49 3 103
79 High High/Low Low Alarm Enable 49 3 17
80 High High/Low Low Alarm Trip High (Low Byte) 49 3 18
81 High High/Low Low Alarm Trip High (High Byte) 49 3 18
82 High High/Low Low Alarm Trip Low Low(Low Byte) 49 3 19
83 High High/Low Low Alarm Trip Low Low(High Byte) 49 3 19
84 High High/Low Low Alarm Deadband (Low Byte) 49 3 20
85 High High/Low Low Deadband (High Byte) 49 3 20
86 Pad Byte (Reserved) 49 … …
87 High/Low Alarm Enable 49 3 22
88 High/Low Alarm Trip High (Low Byte) 49 3 23
89 High/Low Alarm Trip High (High Byte) 49 3 23
90 High/Low Alarm Trip Low (Low Byte) 49 3 24
91 High/Low Alarm Trip Low (High Byte) 49 3 24
92 High/Low Alarm Deadband (Low Byte) 49 3 25
93 High/Low Alarm Deadband High Byte) 49 3 25
94 Pad Byte 1 … … …
95 Pad Byte 2 … … …
Table 34 - Configuration Assemblies for 1734-IE4S Input Modules (continued)
Instance Decimal
(hex)
Byte Field Class
(hex)
Instance
(decimal)
Attribute
(decimal)
Description
