Appendix F I/O Assemblies
864 (360 h) 32 Input Type (Dual Channel Mode) 4B 2 1
Safety Input 1 Configuration Data
33 Input Range 49 2 3
34 Input Channel Mode 49 2 4
35 Filter Setting 49 2
36 Input Error Latch Time (Low Byte) 49 2 8
37 Input Error Latch Time (High Byte) 49 2 8
38 Low Engineering (Low Byte) 49 2 14
39 Low Engineering (High Byte) 49 2 14
40 High Engineering (Low Byte) 49 2 15
41 High Engineering (High Byte) 49 2 15
42 Tach Dual Low Check 49 2 104
43 Tach Trigger 49 2 105
44 Tach OFF Level 49 2 106
45 Tach ON Level 49 2 107
46 Sensor Power Mode 49 2 103
47 High High/Low Low Alarm Enable 49 2 17
48 High High/Low Low Alarm Trip High (Low Byte) 49 2 18
49 High High/Low Low Alarm Trip High (High Byte) 49 2 18
50 High High/Low Low Alarm Trip Low Low(Low Byte) 49 2 19
51 High High/Low Low Alarm Trip Low Low(High Byte) 49 2 19
52 High High/Low Low Alarm Deadband (Low Byte) 49 2 20
53 High High/Low Low Deadband (High Byte) 49 2 20
54 Pad Byte (Reserved) 49 … …
55 High/Low Alarm Enable 49 2 22
56 High/Low Alarm Trip High (Low Byte) 49 2 23
57 High/Low Alarm Trip High (High Byte) 49 2 23
58 High/Low Alarm Trip Low (Low Byte) 49 2 24
59 High/Low Alarm Trip Low (High Byte) 49 2 24
60 High/Low Alarm Deadband (Low Byte) 49 2 25
61 High/Low Alarm Deadband High Byte) 49 2 25
62 Pad Byte 1 … … …
63 Pad Byte 2 … … …
