I/O Assemblies Appendix F
Table 34 - Configuration Assemblies for 1734-IE4S Input Modules
Instance Decimal
(hex)
Byte Field Class
(hex)
Instance
(decimal)
Attribute
(decimal)
Description
864 (360 h) 0 Input Type (Dual Channel Mode) 4B 1 1
Safety Input 0 Configuration Data
1Input Range 491 3
2 Input Channel Mode 49 1 4
3 Filter Setting 49 1
4 Input Error Latch Time (Low Byte) 49 1 8
5 Input Error Latch Time (High Byte) 49 1 8
6 Low Engineering (Low Byte) 49 1 14
7 Low Engineering (High Byte) 49 1 14
8 High Engineering (Low Byte) 49 1 15
9 High Engineering (High Byte) 49 1 15
10 Tach Dual Low Check 49 1 104
11 Tach Trigger 49 1 105
12 Tach OFF Level 49 1 106
13 Tach ON Level 49 1 107
14 Sensor Power Mode 49 1 103
15 High High/Low Low Alarm Enable 49 1 17
16 High High/Low Low Alarm Trip High (Low Byte) 49 1 18
17 High High/Low Low Alarm Trip High (High Byte) 49 1 18
18 High High/Low Low Alarm Trip Low Low(Low Byte) 49 1 19
19 High High/Low Low Alarm Trip Low Low(High Byte) 49 1 19
20 High High/Low Low Alarm Deadband (Low Byte) 49 1 20
21 High High/Low Low Deadband (High Byte) 49 1 20
22 Pad Byte (Reserved) 49 … …
23 High/Low Alarm Enable 49 1 22
24 High/Low Alarm Trip High (Low Byte) 49 1 23
25 High/Low Alarm Trip High (High Byte) 49 1 23
26 High/Low Alarm Trip Low (Low Byte) 49 1 24
27 High/Low Alarm Trip Low (High Byte) 49 1 24
28 High/Low Alarm Deadband (Low Byte) 49 1 25
29 High/Low Alarm Deadband High Byte) 49 1 25
30 Pad Byte 1 … … …
31 Pad Byte 2 … … …
