Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 79
Chapter 5
Configure the Module in a GuardLogix Controller
System
Set up the Module
When using a GuardLogix® controller on an EtherNet/IP network, configure the
POINT Guard I/O™ modules by using the Logix Designer application.
At the bottom of each dialog box, click Help for information about how to
complete entries in that dialog box. At the bottom of warning dialog boxes, click
Help for information about that specific error.
When first setting up your POINT Guard I/O modules on an EtherNet/IP
network, perform the following steps.
1. Add and Configure the Ethernet Bridge
.
2. Add and Configure the 1734 Ethernet Adapter
.
3. Add and Configure Safety Digital Input Modules
.
4. Add and Configure Safety Digital Output Modules
.
5. Add an
d Configure Safety Analog Input Modules.
Topic Page
Set up the Module 79
Add and Configure the Ethernet Bridge 80
Add and Configure the 1734 Ethernet Adapter 80
Add and Configure Safety Digital Input Modules 84
Add and Configure Safety Digital Output Modules 93
Add and Configure Safety Analog Input Modules 98
Values and States of Tags 107
Configure Safety Connections 109
Configuration Ownership 110
Save and Download the Module Configuration 111
You must configure each point that is used as a safety input or output. By
default, all safety input and output points are disabled.
If you need an Add-on Profile, visit the My Support website at
http://support.rockwellautomation.com/ControlFLASH/LogixProfiler.asp.
