Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 139
Configuring Safety Connections between a GuardLogix Controller and POINT Guard I/O Modules on a DeviceNet Network Chapter 7
Individual members of each assembly are listed in Appendix F.
9. Click OK.
10. On the Safety Tab, uncheck the Configuration Signature checkbox.
11. Click OK and OK again to add the module to the I/O Configuration tree.
Table 11 - 1734-IE4S Input Assemblies
Safety Input Connection Input Assembly Safety
Input Number
Input Assembly Safety
Output Number
Size
Safety + Status 402 (192 h) 199 (C7h) 9
Safety + Status + Alarms 786 (312 h) 199 (C7h) 13
Safety + Status + Process Status + Fault
Reason + Alarms
802 (322 h) 199 (C7h) 18
Table 12 - 1734-IE4S Output Assemblies
Safety Output Connection Output Assembly Safety
Input Number
Output Assembly Safety
Output Number
Size
Safety Tachometer 199 (C7h) 770 (302 h) 1
If you are using the 1734-IE4S module with a GuardLogix system, use the
application program to evaluate any dual channel requirements and determine
any process alarms.
