Publication 1746-5.16
9
JW1 Settings
Select 300 µs or 10 ms filtering to debounce the limit switch input. Position the
jumper as follows:
The LS input allows you to make a direct connection to nominal voltage levels of
5, 12, or 24V dc. The ON voltage ranges are as follows:
Refer to pages 19 and 20 for limit switch wiring instructions.
Wiring Terminal ON range
LS (24V dc) 16.5-30V dc
LS (12V dc) 9.4-16.5V dc
LS (5V dc) 3.8-5.5V dc
!
ATTENTION: Only connect one LS input range at a time.
Otherwise, the module will be damaged.
321 321
JW1
10 ms filter
JW1
300 µs filter
