Publication 1763-RM001C-EN-P - October 2009
108 Using the High-Speed Counter and Programmable Limit Switch
HSC Mode 0 - Up Counter
Blank cells = don’t care, ⇑ = rising edge, ⇓ = falling edge
HSC Mode 1 - Up Counter with External Reset and Hold
Blank cells = don’t care, ⇑ = rising edge, ⇓ = falling edge
HSC Mode 0 Examples
Input Terminals I1:0.0/0 (HSC0) I1:0.0/1 (HSC0) I1:0.0/2 (HSC0) I1:0.0/3 (HSC0) CE Bit Comments
Function Count Not Used Not Used Not Used
Example 1 ⇑ on (1) HSC Accumulator + 1 count
Example 2 ⇑ on
(1)
⇓ off (0) off (0) Hold accumulator value
TIP
Inputs I1:0.0/0 through I1:0.0/3 are available for use as
inputs to other functions regardless of the HSC being
used.
HSC Mode 1 Examples
Input Terminals I1:0.0/0 (HSC0) I1:0.0/1 (HSC0) I1:0.0/2 (HSC0) I1:0.0/3 (HSC0) CE Bit Comments
Function Count Not Used Reset Hold
Example 1 ⇑ on
(1)
⇓ off
(0)
off
(0)
on (1) HSC Accumulator + 1 count
Example 2 on
(1)
⇓ off
(0)
on
(1)
Hold accumulator value
Example3 on
(1)
⇓ off
(0)
off (0) Hold accumulator value
Example 4 on
(1)
⇓ off
(0)
on
(1)
⇓ off
(0)
Hold accumulator value
Example 5 ⇑ Clear accumulator (=0)
TIP
Inputs I1:0.0/0 through I1:0.0/3 are available for use as
inputs to other functions regardless of the HSC being
used.
