System Status File 487
RTC Seconds
This address is duplicated in the Real-Time Clock Function File at
RTC:0.SEC
. SeeReal-Time Clock Function File on page 51 for more
information. Note: This value will not update while viewing online in
RSLogix 500. Monitor address in function file to see online values.
RTC Day of Week
This address is duplicated in the Real-Time Clock Function File at
RTC:0.DOW
. SeeReal-Time Clock Function File on page 51 for more
information. Note: This value will not update while viewing online in
RSLogix 500. Monitor address in function file to see online values.
OS Catalog Number
This register identifies the Catalog Number for the Operating System in
the controller.
OS Series
This register identifies the Series letter for the Operating System in the
controller.
Address
(1)
(1) This word can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:42 word 0 to 59 status read only
Address
(1)
(1) This word can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:53 word 0 to 6 status read only
Address Data Format Range Type User Program Access
S:57 word 0 to 32,767 status read only
Address Data Format Range Type User Program Access
S:58 ASCII A to Z status read only
