Publication 1763-RM001C-EN-P - October 2009

526 Protocol Configuration

The Baud defaults to 19200.

The Control Line can be configured as:

• No Handshaking

• Full-Duplex Modem (RTS on)

• Half-Duplex Modem (RTS/CTS handshaking).

• No Handshaking (485 Network)

The Protocol Control defaults are:

• No Handshaking

• InterChar. Timeout = 0

• Pre Transmit Delay = 0.

When the system driver is Modbus RTU Master, the following

communication port parameters can be changed:

NOTE

In order to connect directly to an RS-485 Modbus

network, use a 1763-NC01 cable and configure the

Control Line setting for No Handshaking (485 network).
