Publication 1763-RM001C-EN-P - October 2009

Knowledgebase Quick Starts 547

1. Select “I/O Configuration”

2. Highlight the “MicroLogix 1100“

3. Select “Adv Config“

4. Select the “Embedded I/O Configuration” Tab

5. Adjust Input filters as needed

Problem #2: The HSC instruction does not accumulate counts and the

Error Code (ER) shows a value of (1).

Solution:A file number was entered into (PFN) but the value entered was

less then (3) or greater then (255) or the file number entered was correct,

however the file does not exist.

Create the NEW program file by “Right” mouse clicking on “Program

Files”

efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Default Chapter3
