Rockwell Automation Publication IASIMP-QS023B-EN-P - December 2012 5
Where to Start
Figure 2 - CompactLogix 5370 L3 Controllers Using a DeviceNet Network
1 (Front)
2 (Rear)
PowerFlex 70 Drive with
20-COMM-D Adapter
PowerFlex 40 Drive with 22-
COMM-D Adapter
Computer with
1784-U2DN Cable
Distributed POINT I/O Modules with
1734-ADN Adapter
1606-XLDNET4
DeviceNet Power Supply
CompactLogix 5370 L3
Control System with
1769-SDN Module
Application Configuration
RSNetWorx™ for DeviceNet
Software Configuration
