Publication 1769-UM009B-EN-P - May 2002
Configuring the DeviceNet Network 4-9
4. Select the device you are commissioning in the right panel and
click on OK.
You will see the Node Commissioning window with the
current settings for your scanner. Your window will look similar
to the next one shown in this procedure.
The default scanner settings are:
• baud rate = 125K
• node address = 63
5. In the New Device Settings: Node Address box, enter the new
node address.
6. Click on Apply and Exit the window.
