Publication 1769-UM009B-EN-P - May 2002
4-10 Configuring the DeviceNet Network
Configuring the I/O Devices
The information in this section will focus on the scanner’s
configuration and parameters that you can change using RSNetWorx.
The following screen shows how a DeviceNet network is shown
within RSNetWorx. As you can see, node one is a 1769-SDN scanner.
To view or modify the scanner’s parameters, double-click on the
scanner.
