186 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Appendix G P1 – Floor Level Network (FLN)
(1) Points not listed are not used in this application.
(2) Point numbers that appear in brackets { } may be unbundled at the field panel.
(3) Local Control causes the drive to use C108
[Start Source 2] and C109 [Speed Ref 2] for start and speed reference control.
(4) A single value in a column means that the value is the same in English units and in SI units.
(5) Depends on drive model.
(6) Depending on configuration, units can be volts or milliamperes.
(7) 1 / Secs
Table 49 - Point Database for Application 2735
Point Number Subpoint Name Parameter
01 CTLR ADDRESS C104
02 APPLICATION –
03 FREQ OUTPUT b001
04 PCT OUTPUT d322
05 SPEED d323
06 CURRENT b003
07 TORQUE b013
08 POWER b010
09 DRIVE TEMP b014
11 DRIVE MWH b011
12 RUN TIME b012
13 DC BUS VOLT b005
20 OVRD TIME –
21 FWD.REV MON –
22 CMD FWD.REV –
23 RUN.STOP MON b006, bit 1 (Running)
24 CMD RUN.STOP –
25 READY d302, bit 2 (I/O Terminal 01)
26 RUN ENABLE –
29 DAY NGT –
30 CURRENT LIMT P033
31 ACCEL TIME 1 P039
32 DECEL TIME 1 P040
33 KEYPAD LOCK A198
36 READ PARAM # –
37 READ VALUE –
38 WRITE PARAM # –
39 WRITE VALUE –
40 DIGITAL OUT1 T055, T056
41 DIGITAL OUT2 T060, T061
42 DIGITAL OUT3 T065, T066
43 OPT RELAY 1 R221, R222
(1)
44 OPT RELAY 2 R224, R225
(1)
