P1 – Floor Level Network (FLN) Appendix G
45 OPT RELAY 3 R227, R228
(1)
46 OPT RELAY 4 R230, R231
(1)
47 OPT RELAY 5 R233, R234
(1)
48 OPT RELAY 6 R236, R237
(1)
49 DIGITAL IN 1 d302, bit 0 (I/O Terminal 02)
50 DIGITAL IN 2 d302, bit 1 (I/O Terminal 03)
51 DIGITAL IN 3 d302, bit 2 (I/O Terminal 04)
52 DIGITAL IN 4 d302, bit 3 (I/O Terminal 05)
53 DIGITAL IN 5 d302, bit 4 (I/O Terminal 06)
54 DIGITAL IN 6 d302, bit 5 (I/O Terminal 07)
55 DIGITAL IN 7 d302, bit 6 (I/O Terminal 08)
60 INPUT REF 1 d305
61 INPUT REF 2 d306
62 ANALOG OUT 1 T082
63 ANALOG OUT 2 T085
64 LAST FAULT b007
65 PID GAIN A154
66 PID INT TIME A155
67 PID DIFF RATE A156
68 PID SETPOINT A157
70 CMD DIR MON b006, bit 2 (Forward)
71 ACCELERATING b006, bit 3 (Accelerating)
72 DECELERATING b006, bit 4 (Decelerating)
73 ALARM –
74 AT SPEED –
75 MAIN FREQ d301 (Digit 0)
76 OPER CMD d301 (Digit 1)
77 PARAM LOCK –
78 JOG –
79 LOCAL CNTRL –
80 MOP INC –
81 ACCEL RATE 1 –
82 ACCEL RATE 2 –
83 DECEL RATE 1 –
84 DECEL RATE 2 –
85 REF SELECT 1 –
86 REF SELECT 2 –
87 REF SELECT 3 –
88 MOP DEC –
Table 49 - Point Database for Application 2735
Point Number Subpoint Name Parameter
