Appendix A Specifications
Line Reactors
These line reactors apply to 8720MC-RPS065 and 8720MC-RPS190 units.
Figure 52 - Catalog Numbers 8720MC-LR03-032B, 8720MC-LR048B, 8720MC-LR062B, and
8720MC-LR070B
Line Reactors
Cat. No.
A
(1)
mm (in.)
B
mm (in.)
C
(2)
mm (in.)
D
mm (in.)
E
mm (in.)
F
(3)
mm (in.)
G
mm (in.)
H
(4)
mm (in.)
I
(5)
mm (in.)
J
mm (in.)
K
mm (in.)
Pressure
Terminal
mm (in.)
8720MC-LR03-032B
345
(13.58)
112.5
(4.43)
120
(4.72)
112.5
(4.43)
140
(5.51)
100
(3.94)
4…7
(0.15…0.27)
127
(5.0)
80
(3.14)
15
(0.59)
4…15
(0.15…0.59)
6-(R22-6)
(0.23)
8720MC-LR05-048B
400
(15.74)
132.5
(5.21)
135
(5.31)
132.5
(5.21)
155
(6.10)
105
(4.13)
125
(4.92)
8720MC-LR10-062B
440
(17.32)
145
(5.70)
150
(5.90)
145
(5.70)
160
(6.29)
110
(4.33)
4…9.5
(0.15…0.37)
125
(4.92)
8720MC-LR14-070B
460
(18.11)
155
(6.10)
150
(5.90)
155
(6.10)
180
(7.08)
125
(4.92)
140
(5.51)
(1) The tolerance is ±2 mm (0.07 in.).
(2) The tolerance is ±1 mm (0.03 in.).
(3) The tolerance is +1 mm, -5 mm (+0.03 in. -0.19 in.).
(4) The tolerance is ±5 mm (0.19 in.).
(5) The tolerance is ±10 mm (0.39 in.).
DC
A
G
G
B
F
H
L
K
E
I
J
J
Dimensions are in mm (in.)
