Table 20 - 8720MC Line Reactors for 8720MC-RPS065 Units
Table 21 - 8720MC Line Reactors for 8720MC-RPS190 Units
Table 22 - Wire Ratings for 8720MC Line Reactors
The operating ambient temperature for the 8720MC line reactors is 50 °C
(122 °F), maximum. Derate current 1% for every 1 °C above 50 °C.
Install the Varistor (8720MC-RPS065 units only)
Install a varistor to absorb surge voltage between AC input power wires. The
8720MC-VA-B varistor is the designated varistor for 8720MC-RPS065BM
and 8720MC-RPS065BS units.
Line Reactors
(1)
Cat. No.
(1) Provide the required quantity of reactors for all units connected in parallel (refer to Figure 23 and Figure 24).
Continuous Current, max
A
Inductance
uH
Capacity of Motor, max
kW
8720MC-LR03-032B 32 850 15
8720MC-LR05-048B 48 800 22
8720MC-LR10-062B 62 1100 30
8720MC-LR14-070B 70 1200 37
Line Reactors
(1)
Cat. No.
(1) Cooling fan and thermo switch are mounted on the line reactor unit. The thermo switch opens at about 150 °C (302 °F) and
produces a reactor-fan fault signal.
Quantity
Continuous Current, max
A
Inductance
uH
Capacity of Motor, max
kW
8720MC-LR10-100B
1 100
800
65
2 190 125
Line Reactors
Cat. No.
Continuous Current, max Wire Temperature
8720MC-LR03-032B
≤60 A 105 °C (221 °F) or higher
8720MC-LR05-048B
8720MC-LR10-062B
8720MC-LR14-070B
8720MC-LR14-070B 60…80 A 130 °C (266 °F) or higher
8720MC-LR10-100B – 105 °C (221 °F) or higher
IMPORTANT Provide the required quantity of varistors for all units connected in parallel
and connect the varistor on the incoming AC line-side of the AC contactor.
