Rockwell Automation Publication 8720MC-RM001K-EN-P - September 2018 63
Connect the 8720MC-RPS Unit Chapter 5
Install the Harmonic Filter (8720MC-RPS065 units only)
Install the 8720MC-HF-B2 harmonic filter to remove high-order harmonics
generated by the switching operation of the AC input power modules. Wire
size for the 8720MC-HF-B2 harmonic filter is 3.5 mm
2
(12 AWG).
Install the EMC Line Filter (8720MC-RPS065 units only)
An AC (EMC) line filter is required for meeting the requirements of CE.
Install a line filter for three-phase AC input power and single-phase AC power
for the main magnetic contactors. Line filters are used in power supply and
power regeneration configurations.
Table 23 - Line Filters for 8720MC-RPS065 Units
Install the Line Filter (8720MC-RPS190 units only)
The 8720MC-EF190-VB (EMC) line filter unit contains line filter, magnetic
contactor, varistor, harmonic filter, and is used with the
8720MC-RPS190BM and 8720MC-RPS190BS regenerative power supplies.
Because the 8720MC-EF190-VB unit is completely assembled, the wiring can
be simplified in combination with 8720MC-LR10-100B reactors. For wiring
the 8720MC-EF190-VB unit, refer to Figure 25
, Figure 26, and Figure 27.
Table 24 - Recommended Power Wire Sizes
IMPORTANT Connect the harmonic filter on the incoming AC line-side of the AC
contactor.
8720MC-RPS
Cat. No.
Three-phase AC Power for
AC Input Power Line
Single-phase AC Power for
Main Magnetic Contactor
Allen-Bradley®
Cat. No.
Soshin Electric PN Schaffner PN Soshin Electric PN
8720MC-RPS065BM
8720MC-RFI80 HF3080C-TOA FN2010-6-06 NF2005A-YX
8720MC-RPS065BS
Terminal Block Terminals Screw Size Wire Size Attached Lug
(1)
Torque
Mains (input) L1, L2, L3 M8
Larger than 38 mm
2
-2 in parallel
(2-2 AWG in parallel)
JST, R38-8 (M8)
(6 pieces)
5.5…6.6 N•m
(48…57 lb•in)
Mains (output) L4, L5, L6 M10
JST, R38-10 (M10)
(6 pieces)
10…12 N•m
(89…106 lb•in)
Ground (earth) G M8 Larger than 38 mm
2
(2 AWG)
JST, R38-8 (M8)
(1 piece)
5.5…6.6 N•m
(48…57 lb•in)
(1) UL-Listed wires must be lugged by attached lugs. JST is Japan Solderless Terminal Co.
