Allen-Bradley 8720MC-RPS065 - Harmonic Filter

Rockwell Automation Publication 8720MC-RM001K-EN-P - September 2018 117
Specifications Appendix A
Harmonic Filter
These harmonic filters apply to 8720MC-RPS065 units.
Figure 55 - Catalog Number 8720MC-HF-B2
R
S
T
Equivalent Circuit
2 Oval Holes of 5.5 x 8.0
(0.22 x 0.31)
R
ST
N
E
M5
NE
22.5 ±1.5
(0.89)
1 MΩ
15 μF
6 ± 1 (0.24)
t1.5 (0.06)
17.5 ±1.5
(0.69)
35 ± 1
(1.38)
35 ± 1
(1.38)
17.5 ±1.5
(0.69)
40 ±1.5
(1.57)
119.5 ± 1.5
(4.70)
105 ±1.5
(4.13)
131.5 ± 1.5
(5.18)
Display
t1.2 (0.05)
55 ±1.5
(2.17)
15 ±1.5
(0.59)
39 ±1.5
(1.53)
65 ±1.5
(2.56)
13 ±1.5
(0.51)
1 MΩ
0.47 μF
Dimensions are in mm (in.)
