14 Rockwell Automation Publication 842E-UM001C-EN-P - September 2016
Chapter 2 Encoder Overview
Special Features
Properties Encoder
Single-turn Multi-turn
Absolute Encoder in 60 mm (2.36 in.) design
■■
Robust nickel code disk for harsh environment
■■
High precision and reliability
■■
Ball bearings are spaced 30 mm (1.18 in.) apart
■■
High level of resistance to vibration
■■
Optimal rotational accuracy
■■
Compact design
■■
Face mount flange, servo flange and blind
■■
Hollow shaft
■■
ControlFLASH upgradable
■■
18-bit single-turn resolution (1 to 262,144 steps)
■■
30-bit total resolution
■
12-bit multi-turn resolution (1…4,096 revolutions)
■
Round axis functionality/endless shaft functionality
■
EtherNet/IP interface (as per IEC 61784-1)
■■
Supports the encoder profile 22h defined in the CIP (Common Industrial
Protocol)
■■
Device Level Ring (DLR)
■■
