How to fix Allen-Bradley Media Converter when module status is off?
If the module status is off on your Allen-Bradley Media Converter, it's likely because the device isn't receiving power. To resolve this, ensure that power is correctly applied to the device.
What to do if the network status is off on Allen-Bradley Media Converter?
If the network status is off on your Allen-Bradley Media Converter, it indicates the device is not online, hasn't completed the dup_MAC_id test, or isn't powered. Start by verifying that power is applied to the device.
What to do if Allen-Bradley 1734-SSI Media Converter module status is flashing red?
If the module status on your Allen-Bradley Media Converter is flashing red, it signifies a recoverable fault. Try cycling the power to the device. If the problem continues, consider replacing the device.
Why is the network status solid red on my Allen-Bradley 1734-SSI?
A solid red network status on your Allen-Bradley Media Converter indicates a critical link failure with a failed communication device, meaning the device detected an error preventing network communication. Verify that the adapter and terminal bases are properly installed, and reinstall if needed.
How to fix Allen-Bradley 1734-SSI Media Converter when module status is flashing green?
If the module status on your Allen-Bradley Media Converter is flashing green, it means the device requires commissioning due to a missing, incomplete, or incorrect configuration. You should configure the device properly.
What does it mean if the network status is flashing red on an Allen-Bradley Media Converter?
A flashing red network status on your Allen-Bradley Media Converter indicates that one or more I/O connections have timed out. Check for any module failures and correct them as necessary.
What to do if Allen-Bradley Media Converter network status is flashing red/green?
If the network status on your Allen-Bradley Media Converter is flashing red and green, it indicates a communication faulted device. This means the device detected a network access error and is in a communication faulted state, or it received and accepted an Identify Communication Faulted Request. Verify that the adapter is properly installed, and reinstall it if needed.
What does solid red module status mean on Allen-Bradley Media Converter?
A solid red module status on your Allen-Bradley Media Converter indicates an unrecoverable fault that may require device replacement.
Why is the run status off on my Allen-Bradley Media Converter?
If the run status is off on your Allen-Bradley Media Converter, it means the module is commanded to stop retrieving SSI data. Turn the run on to begin collecting SSI data.
General| Brand | Allen-Bradley |
|---|---|
| Model | 1734-SSI |
| Category | Media Converter |
| Language | English |
Explains the manual's objective and scope for users.
Identifies the target audience and required user knowledge.
Lists related publications and resources for further information.
Provides a general overview of the 1734-SSI module and its function.
Details the procedure for installing the mounting base assembly on a DIN rail.
Describes how to correctly install the 1734-SSI module into its base.
Explains the steps for inserting the removable terminal block into the module.
Provides instructions on how to detach the mounting base from the DIN rail.
Covers the wiring connections required for the 1734-SSI module.
Guides users on adding the communication adapter to the network.
Explains how to integrate the 1734-SSI module into the network via the scanner.
Details how to configure the module's parameters for the connected encoder.
Describes how to verify module status and access its Electronic Data Sheet.
Introduces communication methods and supported connection types for the module.
Explains how the module exchanges real-time input/output data.
Discusses the module's operating modes and associated parameters.
Defines key configurable parameters for the 1734-SSI module.
Details the functionality and usage of data latch and comparator features.
Covers additional features and status indicators of the module.
Provides a practical example of module configuration with a specific sensor.
Explains how to interpret module indicators for problem diagnosis.
Explains data formats, connection types, and communication formats for adapters.
Outlines the steps to configure modules using RSLogix 5000 software.
Guides users on accessing help within the RSLogix 5000 configuration dialogs.
Details how to use the Feedback dialog for module configuration.
Explains the usage of the Conversion dialog for module settings.
Describes how to configure the Input Registration dialog for module settings.
Details the use of the Watch Position dialog for module configuration.
