10 FLEX I/O Digital DC Output Modules
Publication 1794-IN094C-EN-P - July 2015
Wiring Connections for 1794-OB8EP
1794-TB2, 1794-TB3, 1794-TB3S 1794-TBN
Output Output
Terminal
Common
Terminal
(1)
Output
Terminal
Common
Terminal
(2)
Output 0 A-0 A-1/B-17 B-0 C-1
Output 1 A-2 A-3/B-19 B-2 C-3
Output 2 A-4 A-5/B-21 B-4 C-5
Output 3 A-6 A-7/B-23 B-6 C-7
Output 4 A-8 A-9/B-25 B-8 C-9
Output 5 A-10 A-11/B-27 B-10 C-11
Output 6 A-12 A-13/B-29 B-12 C-13
Output 7 A-14 A-15/B-31 B-14 C-15
+V DC C-34 to C-51 (C-34 and C-51 for 1794-TB2, 1794-TBN)
Common B-16 to B-33 (B-16 and B-33 for 1794-TBN)
(1)
1794-TB2, 1794-TB3,1794 -TB3S – A-1, A-3, A-5, A-7, A-9, A-11, A-13, and A-15 are connected together inside the
module to 24V DC common.
(2)
1794-TBN – C-1, C-3, C-5, C-7, C-9, C-11, C-13, and C-15 are connected together inside the module to 24V DC common.
