FLEX I/O Digital DC Output Modules 9
Publication 1794-IN094C-EN-P - July 2015
Wiring Connections for 1794-OB8, 1794-OB16, and 1794-OB16P
(used with 1794-TB2, 1794-TB3, or 1794-TB3S Terminal Base Unit)
Output
(1)
(1)
1794-OB8 – Outputs 0...7; 1794-OB16 and 1794-OB16P – Outputs 0...15
Output Terminal Common Terminal
Output 0 A-0 B-17
Output 1 A-1 B-18
Output 2 A-2 B-19
Output 3 A-3 B-20
Output 4 A-4 B-21
Output 5 A-5 B-22
Output 6 A-6 B-23
Output 7 A-7 B-24
Output 8 A-8 B-25
Output 9 A-9 B-26
Output 10 A-10 B-27
Output 11 A-11 B-28
Output 12 A-12 B-29
Output 13 A-13 B-30
Output 14 A-14 B-31
Output 15 A-15 B-32
+V DC C-34 to C-51 (C-34 and C-51 for 1794-TB2
Common B-16 to B-33
