FLEX I/O Digital DC Output Modules 13
Publication 1794-IN094C-EN-P - July 2015
Wiring Connections for 1794-OB32P
(used with 1794-TB32 or 1794-TB32S Terminal Base Unit)
Output Output Terminal Common Power
Output 0 A-0 Connect common to
terminals 36, 38, 40, and
42
Connect power to
terminals 35, 37, 39, and
41Output 1 A-1
Output 2 A-2
Output 3 A-3
Output 4 A-4
Output 5 A-5
Output 6 A-6
Output 7 A-7
Output 8 A-8
Output 9 A-9
Output 10 A-10
Output 11 A-11
Output 12 A-12
Output 13 A-13
Output 14 A-14
Output 15 A-15
