14 FLEX I/O Digital DC Output Modules
Publication 1794-IN094C-EN-P - July 2015
Output 16 B-17 Connect common to
terminals 44, 46, 48, and
50
Connect power to
terminals 43, 45, 47, and
49Output 17 B-18
Output 18 B-19
Output 19 B-20
Output 20 B-21
Output 21 B-22
Output 22 B-23
Output 23 B-24
Output 24 B-25
Output 25 B-26
Output 26 B-27
Output 27 B-28
Output 28 B-29
Output 29 B-30
Output 30 B-31
Output 31 B-32
For Outputs 0...15, use +V1 and COM1
+V1 DC power Power terminals 35, 37, 39, and 41
Com1 DC Return Common terminals 36, 38, 40, and 42
For Outputs 16...31, use +V2 and COM2
+V2 DC power Power terminals 43, 45, 47, and 49
Com2 DC Return Common terminals 44, 46, 48, and 50
Wiring Connections for 1794-OB32P
(used with 1794-TB32 or 1794-TB32S Terminal Base Unit)
Output Output Terminal Common Power
