Allen-Bradley Kinetix 6500 - Kinetix 350 Drive Module Optional Attributes

Chapter 3
Interpret the Attribute Tables
116 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
Attribute Conversion from SERCOS to Integrated Motion on the
Ethernet/IP Network on page 111
MSG Instruction Access Only Attributes on page 181
A Kinetix 350 drive module supports the following optional attributes and
corresponding control mode functionalities:
ID Access
Rule
Attribute Name B E F P V T Conditional Implementation
367 Get Acceleration Fine Command - - Y Y Y
485 Set Acceleration Limit - N N N N
482 Get Acceleration Reference - - N N N
481 Set Acceleration Trim - - N N N
1376 Set Actuator Diameter N N N N N DScale
1377 Set Actuator Diameter Unit N N N N N DScale
1374 Set Actuator Lead N N N N N DScale
1375 Set Actuator Lead Unit N N N N N DScale
1373 Set Actuator Type N N N N N DScale
732/267 Get Analog Input 1 Y - N N N N
733/268 Get Analog Input 2 Y - N N N N
734 Set Analog Output 1 Y - N N N N
735 Set Analog Output 2 Y - N N N N
30 Set Axis Configuration R R R R R O-Enum
0 = Feedback Only (N)
1 = Frequency Control (N)
2 = Position Loop (Y)
3 = Velocity Loop (Y)
4 = Torque Loop (Y)
19 Set Axis Features R R R R R O-Bits
0 = Fine Interpolation (Y)
1 = Registration Auto-rearm (Y)
2 = Alarm Log (Y)
5 = Hookup Test (Y)
6 = Commutation Test (N)
7 = Motor Test (N)
8 = Inertia Test (Y)
9 = Sensorless Control (N)
763 Get Axis Safety Faults O O O O Y
760 Get Axis Safety State O O O O Y
761 Get Axis Safety Status O O O O Y
825 Set Backlash Compensation Window - - N - -
638/262 Get Bus Regulator Capacity - N N N N
659 Get CIP Axis Alarms N N N N N
904 Get CIP Axis Alarms - RA N N N N N
Kinetix 350 Drive Module
Optional Attributes
