Allen-Bradley MicroLogix 1200 Reference Manual

Publication 1762-RM001C-EN-P
File Instructions 14-7
•
Bit Address - The source is the address of the bit to be transferred into
the bit array at the last (highest) bit position.
•
Length - The length operand contains the length of the bit array in
bits. The data range for length is from 0 to 2048.
Addressing Modes and File Types can be used as shown in the following
table:
Table 14.9 BSR Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page4-2.
Parameter
Data Files Function Files
CS - Comms IOS - I/O
Address
Mode
(1)
(1) See Important note about indirect addressing.
Address
Level
O I S B T, C, R N L ST MG, PD RTC HSC PTO, PWM STI EII BHI MMI DAT TPI Immediate Direct Indirect Bit Word Long Word Element
File •• • •• • •••
Control
(2)
(2) Control file only. Not valid for Timers and Counters.
• •
Length
• •
Source •• ••••
• ••
IMPORTANT
You cannot use indirect addressing with: S, ST, MG, PD,
RTC, HSC, PTO, PWM, STI, EII, BHI, MMI, DAT, TPI, CS,
IOS, and DLS files.

Allen-Bradley MicroLogix 1200 Specifications

General

Series	MicroLogix 1200
Type	Programmable Logic Controller (PLC)
Mounting	DIN rail or panel mount
Programming Language	Ladder Logic
Programming Software	RSLogix 500
I/O Points	Up to 40
Communication Ports	RS-232, RS-485
Memory	6 KB user memory
Power Supply	24V DC or 120/240V AC
Expansion	Supports expansion I/O modules
Operating Temperature	0°C to 55°C (32°F to 131°F)
Dimensions	90 mm x 110 mm
Weight	0.5 kg (1.1 lbs)
