Publication 1762-RM001C-EN-P
20-12 ASCII Instructions
to be sent or, send data on a time interval. If sent on a time interval, use
an interval of 0.5 second or greater.
This instruction executes on a true rung. Once started, if the rung goes
false, the instruction continues to completion. If you want to repeat this
instruction, the rung must transition from false-to-true.
When using this instruction you can also perform in-line indirection. See
page 20-29 for more information.
Entering Parameters
Enter the following parameters when programming this instruction:
Channel is the number of the RS-232 port, Channel 0. (For the
1764-LRP only, you can select either Channel 0 or Channel 1).
Source is the string element you want to write.
Control is the control data file. See page 20-6.
String Length (.LEN) is the number of characters you want to write
from the source string (0 to 82). If you enter a 0, the entire string is
written. This is word 1 in the control data file.
Characters Sent (.POS) is the number of characters that the controller
sends to an external device. This is word 2 in the control data file.
Characters Sent (.POS) is updated after all characters have been
transmitted.
The valid range for .POS is from 0 to 82. The number of characters
sent to the destination may be smaller or greater than the specified
String Length (.LEN) as described below:
Characters Sent (.POS) may be smaller than String Length (.LEN) if
the length of the string sent is less than what was specified in the
String Length (.LEN) field.
Characters Sent (.POS) can be greater than the String Length
(.LEN) if inserted values from in-line indirection are used. If the
String Length (.LEN) is greater than 82, the string written to the
destination is truncated to 82 characters.
Error displays the hexadecimal error code that indicates why the ER
bit was set in the control data file. See page 20-30 for error code
descriptions.
IMPORTANT
Do not continuously generate streams of ASCII data out of
a communications port. If ASCII write instructions execute
continuously, you may not be able to re-establish
communications with RSLogix 500 when the controller is
placed into the RUN mode.
