Allen-Bradley MicroLogix 1761-NET-ENI - Default Settings

Publication 1761-UM006A-EN-P - February 2001
Product Overview 1-3
Default Settings
The ENI’s RS-232 port has the following default settings:
Table 1.1 RS-232 Settings
Setting Default Other Options
Baud Rate Autobaud see table 4.7
Handshaking (hardware, software) none none
Data Bits 8 none
Stop Bits 1 none
Parity none none
Table 1.2 DF1 Settings
Setting Default Other Options
Duplicate Message Detection Enable none
Error Detection CRC, BCC Auto-detect when
Autobaud is true,
otherwise CRC
Embedded Response Operation Auto-Detect, for
reception only
(1)
(1) The ENI receives NAKs and ACKs, but does not generate them.
none
DLE ACK Timeout 1 second none
DLE NAK Receive 3 NAK retries none
DLE ENQ for Response 3 ENQs retries none
DF1 Node Address Don’t Care
