Allen-Bradley MicroLogix 1761-NET-ENI User Manual

Publication 1761-UM006A-EN-P - February 2001
A-2 Specifications
Dimensions
52.07 mm
(2.05 in.)
27.7 mm
(1.09 in.)
118 mm
(4.64 in.)
107 mm
(4.20 in.)
64.8 mm
(2.55 in.)
Allow 15 mm (0.6 in.)
clearance for DIN rail
latch movement during
installation and removal.
52.07 mm
(2.05 in)
27.7 mm
(1.09 in)
107 mm
(4.20 in)
118 mm
(4.64 in)
Allow 15 mm (0.6 in.) clearance
for DIN rail latch movement
during installation and removal.
Product Dimensions
Mounting Dimensions

Allen-Bradley MicroLogix 1761-NET-ENI Specifications

General

Brand	Allen-Bradley
Model	MicroLogix 1761-NET-ENI
Category	Recording Equipment
Language	English
