Allen-Bradley MicroLogix 1761-NET-ENI User Manual

1 Publication 1761-UM006A-EN-P - February 2001
Chapter 4
ENI Configuration (Node 248 to 254)
This chapter describes configuration methods and parameters. It is
arranged as follows:
• Configuration Methods
• ENI Configuration Utility
• Controller Messaging
• Configuring ENI Data Parameters
• Configuring ENI String Parameters
• ENI Configuration Parameters
Configuration Methods
The ENI’s IP information can be entered using either:
• the ENI Configuration Utility
• a write message from the Allen-Bradley controller to node
address 250
• the BOOTP Utility over Ethernet (BOOTP configuration is
described in Appendix B of this manual)
ENI Configuration Utility
The ENI Configuration Utility is free software designed for configuring
the ENI. It is available from http://www.ab.com/micrologix
.
TIP
When using the ENI Configuration Utility, be
sure to use a 1761-CBL-PM02 Series C cable
between the ENI and the computer.
