Allen-Bradley MicroLogix 1762-IF2OF2 User Manual

MicroLogix™ Analog Input/Output Module 11
Publication 1762-IN005A-US-P
Sensor/Transmitter Types
(1) All power supplies rated N.E.C. Class 2.
Labeling the Terminals
A write-on label is provided with the module. Mark the identification of each
terminal with permanent ink, and slide the label back into the door.
+
+
-
-
+
-
+
-
IN +
IN -
COM
+
-
IN +
IN -
COM
+
-
IN +
IN -
COM
Power
Supply
(1)
Power
Supply
(1)
Power
Supply
(1)
Transmitter
Transmitter
Transmitter
Module
Module
Module
Supply Signal
Supply Signal
2-Wire Transmitter
3-Wire Transmitter
4-Wire Transmitter
