18 MicroLogix™ Analog Input/Output Module
Publication 1762-IN005A-US-P
Specifications
General Specifications
Specification Value
Dimensions 90 mm (height) x 87 mm (depth) x 40 mm (width)
height including mounting tabs is 110 mm
3.54 in. (height) x 3.43 in. (depth) x 1.58 in. (width)
height including mounting tabs is 4.33 in.
Approximate Shipping Weight
(with carton)
240g (0.53 lbs.)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Operating Temperature 0°C to +55°C (-32°F to +131°F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude 2000 meters (6561 feet)
Vibration Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak
Shock Operating: 30G
Bus Current Draw (max.) 40 mA at 5V dc
105 mA at 24V dc
Analog Normal Operating Range Voltage: 0 to 10V dc
Current: 4 to 20 mA
Full Scale
(1)
Analog Ranges
Voltage: 0 to 10.5V dc
Current: 0 to 21 mA
Resolution 12 bits (unipolar)
Repeatability
(2)
±0.1%
Input and Output Group to System
Isolation
30V ac/30V dc rated working voltage
(3)
(N.E.C. Class 2 required)
(IEC Class 2 reinforced insulation)
type test: 500V ac or 707V dc for 1 minute
Module Power LED On: indicates power is applied.
Recommended Cable Belden™ 8761 (shielded)
