MicroLogix™ Analog Input/Output Module 19
Publication 1762-IN005A-US-P
Vendor I.D. Code 1
Product Type Code 10
Product Code 75
Agency Certification C-UL certified (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives
Hazardous Environment Class Class I, Division 2, Hazardous Location, Groups A, B, C, D (UL
1604, C-UL under CSA C22.2 No. 213)
Noise Immunity NEMA standard ICS 2-230
Radiated and Conducted Emissions EN50081-2 Class A
Electrical /EMC: The module has passed testing at the following levels:
ESD Immunity (IEC1000-4-2) 4 kV contact, 8 kV air, 4 kV indirect
Radiated Immunity (IEC1000-4-3) 10 V/m, 80 to 1000 MHz, 80% amplitude modulation, +900
MHz keyed carrier
Fast Transient Burst (IEC1000-4-4) 2 kV, 5 kHz
Surge Immunity (IEC1000-4-5) 1 kV galvanic gun
Conducted Immunity (IEC1000-4-6)
10V, 0.15 to 80 MHz
(4)
(1) The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The
module continues to convert the analog input up to the maximum full scale range.
(2) Repeatability is the ability of the input module to register the same reading in successive measurements for
the same input signal.
(3) Rated working voltage is the maximum continuous voltage that can be applied at the terminals with respect
to earth ground.
(4) Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is
30 MHz to 1000 MHz.
Specification Value
