MicroLogix™ Analog Input/Output Module 17
Publication 1762-IN005A-US-P
Bit 15 and Bits 7 through 0 - Reserved
These bits are reserved and are not checked by the module.
Data Format (Bits 14 through 12)
These bits indicate the format of the data as shown in the following table. Other
combinations of these bits are not supported and result in an error.
Type/Range Select (Bits 11 through 8)
These bits indicate the type and range as in the following table. Other
combinations of these bits are not supported and result in an error.
Bit Settings
Data Format
14 13 12
0 0 0 Raw/Proportional
0 1 0 Scaled for PID
other Not Supported
Bit Settings
Data Format
11 10 9 8
0 0 1 0 Voltage Mode 0 to 10V dc
0 0 1 1 Current Mode 4 to 20 mA
other Not Supported
