MicroLogix™ Analog Input/Output Module 21

Publication 1762-IN005A-US-P

Output Specifications

Specification Value

Number of Outputs 2 single-ended (unipolar)

D/A Converter Type Resistor string

Resistive Load on Current

Output

0 to 500 Ω (includes wire resistance)

Load Range on Voltage Output > 1KΩ

Reactive Load, Current Output < 0.1 mH

Reactive Load, Voltage Output < 1 µF

Typical Overall Accuracy

(1)

(1) Includes offset, gain, non-linearity and repeatability error terms.

±1% full scale at 0 to 55°C

±0.5% full scale at 25°C

Output Ripple

range 0 to 500 Hz

(referred to output range)

< ±0.1%

Non-linearity (in percent full

scale)

< ±0.5%

Open and Short-Circuit

Protection

Continuous

Output Protection ±32 mA
