Allen-Bradley PanelView 600 User Manual

41061-004-01(D)
Installation Instructions
English
PanelView 600 Terminals
(Catalog Numbers 2711-K6Cxx, 2711-B6Cxx)
Inside:
For More Information.............................................................................. 4
Hazard Locations..................................................................................... 4
European Union Directive Compliance ................................................... 5
Wiring and Safety Guidelines................................................................. 6
Enclosures............................................................................................... 6
Required Tools......................................................................................... 6
Mounting Dimensions............................................................................. 7
Cutout Dimensions.................................................................................. 7
Clearances .............................................................................................. 8
Installing Terminal in a Panel.................................................................. 9
Installing the Memory Card .................................................................. 11
Connecting AC Power........................................................................... 12
Connecting DC Power........................................................................... 13

Allen-Bradley PanelView 600 Specifications

General

Input Type	Touchscreen
Power Supply	24V DC
Communication Ports	RS-232
Operating Temperature	0°C to 50°C
Relative Humidity	5% to 95% non-condensing
