Allen-Bradley PanelView Plus 1000 User Manual

Publication 2711P-UM001A-EN-P
Terminal Connections 6-7
Computer or Printer Connections
The RS-232 serial port on the base configured unit of the PanelView
Plus terminal supports:
• application uploads/downloads using a direct connection
• or printing
Printer
RS-232 Port
RS-232 Port
9-pin male
1
2
3
4
5
6
7
8
9
TXD (Data Transmit)
RXD (Data Receive)
COM
DTR
DSR
RTS
CTS
NC
DCD
9-pin male
1
2
3
4
5
6
7
8
9
(pulled high to +12V)
NC
NC
NC
PanelView Plus Port (DCE)
Printer/Computer Port (DTE)
Available Cables
Cat. No. 2711-NC13, 5 m (16.4 ft)
Cat. No. 2711-NC14, 10 m (32.7 ft)
Cat. No. 2706-NC13, 3 m (10 ft)
25-pin to 9-pin
Adapter
(if required)
with Handshaking
RXD
TXD
COM
RTS
CTS
9-pin male
PanelView Plus Printer Port (DCE)
2
3
9-pin
2
3
5
Printer/Computer Port (DTE)
25-pin
2
7
3
5
COM
Upload/Download or Printer Cable without Hardware Handshaking
RXD
TXD
COM
Computer
Base Configured Unit of PanelView Plus
AB PLCs

Allen-Bradley PanelView Plus 1000 Specifications

General

Display Size	10.4 inches
Resolution	640 x 480 pixels
Touchscreen	Analog resistive
Operating System	Windows CE
Memory	64 MB RAM
Storage	64 MB Flash
Communication Ports	Ethernet, RS-232, USB
Input Voltage	24V DC
Display Type	Color TFT
Processor	XScale
Enclosure	NEMA 4X
Operating Temperature	0°C to 50°C
