Overview Chapter 1
Catalog Number
Explanation
This is the catalog number explanation for configured units of the
PanelView Plus 6 terminals.
Terminal Selections
The PanelView Plus 6 configured terminals have logic modules with or without
extended features and file viewers. Communication modules are ordered as
separate catalog numbers.
Input
Type
Display
Size
Display
Type
Communication
(1)
Power
Operating System
Special Option
2711P- K = Keypad 7 = 6.5 in. C = Color 4 = Ethernet, RS-232 & (2) USB A = AC 8= Windows CE 6.0 operating system K = Conformal-Coated
T = Touch 10 = 10.4 in. D = DC 9 = Windows CE 6.0 operating system
with extended features
B = Keypad/Touch 12 = 12.1 in.
15 = 15 in.
(1) Optional communication modules are available as separate catalog numbers.
Table 6 - PanelView Plus 6 Terminals
Cat. Nos. Display Communication
Input
Power
Nonvolatile Flash/
RAM Memory
(2)
Keypad Touch Keypad/Touch Size Typ e RS-232 Ethernet
700 Model
2711P-K7C4D8 2711P-T7C4D8 2711P-B7C4D8 6.5-in. Color • • DC 512 MB/512 MB
– 2711P-T7C4D8K
(1)
– • • DC 512 MB/512 MB
2711P-K7C4A8 2711P-T7C4A8 2711P-B7C4A8 • • AC 512 MB/512 MB
1000 Model
2711P-K10C4D8 2711P-T10C4D8 2711P-B10C4D8 10.4-in Color • • DC 512 MB/512 MB
2711P-K10C4A8 2711P-T10C4A8 2711P-B10C4A8 • • AC 512 MB/512 MB
1250 Model
2711P-K12C4D8 2711P-T12C4D8 2711P-B12C4D8 12.1-in Color • • DC 512 MB/512 MB
– 2711P-T12C4D8K
(1)
– • • DC 512 MB/512 MB
2711P-K12C4A8 2711P-T12C4A8 2711P-B12C4A8 • • AC 512 MB/512 MB
1500 Model
2711P-K15C4D8 2711P-T15C4D8 2711P-B15C4D8 15-in. Color • • DC 512 MB/512 MB
2711P-K15C4A8 2711P-T15C4A8 2711P-B15C4A8 • • AC 512 MB/512 MB
(1) Conformal-coated terminal.
(2) The logic module supports FactoryTalk View Machine Edition software, version 6.0 or later, FactoryTalk ViewPoint software version 1.2 or later, and the
Windows CE 6.0 operating system.
