Publication 1734-UM005B-EN-P - June 2001
B-2 Default Data Maps
1734-IB2 Sink Input Module
Product Code: 0081h
Data Map:
Output size: 0 bytes; Input size: 1 byte
Configuration Data:
Filter Values
Default: H00 (1ms)
Diagnostic Data
Possible Error Codes:
7654321 0
Produces (Rx) Not used CH1
state
CH0
state
Consumes (Tx) No consumed data
Where: CH0 = input channel 0, CH1 = input channel 1; 0 = OFF, 1 = ON
7654321 0
Reserved Filter
Meaning of bits described below
Value Definition
00 1ms
01 0.33ms
10 3ms
11 10ms
Error Code Error Type
16 Module incorrect or missing. Reported on channel 0 and applies to
whole module.
