Allen-Bradley POINT I/O PROFIBUS 1734-APB User Manual

Publication 1734-UM005B-EN-P - June 2001
Default Data Maps B-7
1734-OB4E Electronically
Protected Output Module
Product Code: 0086h
Data Map:
Output size: 1 bytes; Input size: 0 byte
Configuration Data:
Default: H10 (Default: Fault/Idle value = OFF, No load, Latch)
Diagnostic Data
Possible Error Codes:
7654321 0
)Produces (Rx) No produced data
Consumes (Tx) Not used CH3
state
CH2
state
CH1
state
CH0
state
Where: CH0, CH1, CH2, CH3; 0 = OFF, 1 = ON
7654321 0
Reserved RM NL IV IA FV FA
Meaning of bits described below
FA = Fault Action FV = Fault Value
Value Definition Value Definition
0 Fault Value 0 OFF
1 Hold Last State 1 ON
IA = Idle Action IV = Idle Value
Value Definition Value Definition
0 Idle Value 0 OFF
1 Hold Last State 1 ON
NL = No Load Enble RM = Reset Mode
Value Definition Value Definition
0 Disable 0 Latch
1 Enable 1 Auto Retry
Code Error Type
4 Overload
6 Wire Break
16 Module incorrect or missing. Reported on channel 0, applies to whole module.
