Rockwell Automation Publication 750-IN001O-EN-P - October 2014 117
Lift and Mount the Drive Chapter 3
Figure 78 - Bus Bar Dimensions (MCC Bus)
Dimensions are in millimeters and (inches).
971.6
(38.25)
1301.8
(51.25)
971.6
(38.25)
1136.7
(44.75)
1301.8
(51.25)
Common DC Input DriveAC Input Drive
