186 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 4 Power Wiring
21G…C910 LD 560 100
These options are not used with these drive ratings.
ND 500 100
HD 400 100
21G…C1K0 LD 630 100
ND 560 100
HD 500 100
21G…C1K1 LD 710 100
ND 630 100
HD 500 100
21G…C1K2 LD 800 100
ND 710 100
HD 560 100
21G…C1K4 LD 850 100
ND 800 100
HD 630 100
21G…C1K5 LD 900 100
ND 850 100
HD 710 100
(1) These circuit breakers are considered Branch Circuit Protection for the unit.
(2) No additional protection is provided with the P5 Molded Case Switch option. Branch circuit protection is required based on NEC guidelines.
Drive Catalog
Number
Duty
Cycle kW
Short Circuit Current Rating (kA)
Circuit Breaker
Only (P3)
(1)
Circuit Breaker with Input Contactor
(P3 with P11)
(1)
Molded Case Switch Only
(P5)
(2)
Molded Case Switch with Input Contactor
(P5 with P11)
(2)
400 Volt AC Input
