Allen-Bradley PowerFlex 20-750-ENC-1

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 187
Power Wiring Chapter 4
Drive Catalog
Number
Duty
Cycle Hp
Short Circuit Current Rating (kA)
Circuit Breaker
Only (P3)
(1)
Circuit Breaker with Input Contactor
(P3 with P11)
(1)
Molded Case Switch Only
(P5)
(2)
Molded Case Switch with Input Contactor
(P5 with P11)
(2)
480 Volt AC Input
21G…D430 LD 400 100 30 or
• 65 w/600 A Class J fuse
65 5 or
• 65 w/600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
ND 350 100 30 or
• 65 w/550…600 A Class J fuse
65 30 or
• 65 w/550…600 A Class J fuse
HD 300 100 5 or
• 100 w/450…600 A Class J fuse
• 18 w/600…800 A Class L fuse
• 18 w/500 A CB
65 5 or
• 100 w/500…600 A Class J fuse
• 18 w/600…800 A Class L fuse
• 18 w/500 A CB
21G…D485 LD 450 100 30 65 or
• 100 w/800 A Class L fuse
5 or
• 30 w/650…1200 A Class L fuse
• 30 w/700…1200 A CB
ND 400 100 30 or
• 65 w/600 A Class J fuse
65 5 or
• 65 w/600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
HD 350 100 5 or
• 100 w/500…600 A Class J fuse
• 18 w/600…900 A Class L fuse
65 5 or
• 100 w/500…600 A Class J fuse
• 18 w/600…900 A Class L fuse
21G…D545 LD 500 100 30 65 or
• 100 w/800 A Class L fuse
5 or
• 30 w/700…1300 A Class L fuse
• 30 w/700…1200 A CB
ND 450 100 30 65 or
• 100 w/650…800 A Class L fuse
5 or
• 30 w/650…1200 A Class L fuse
• 30 w/700…1200 A CB
HD 350 100 30 or
• 65 w/550…600 A Class J fuse
65 5 or
• 65 w/550…600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
21G…D617 LD 600 100 42 65 or
• 100 w/850…1200 A Class L fuse
5 or
• 42 w/850…1500 A Class L fuse
• 42 w/900…1200 A CB
ND 500 100 30 65 or
• 100 w/750…800 A Class L fuse
5 or
• 30 w/750…1300 A Class L fuse
• 30 w/800…1200 A CB
HD 400 100 30 or
• 65 w/600 A Class J fuse
65 5 or
• 65 w/600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
21G…D710 LD 650 100 42 65 or
• 100 w/1000…1200 A Class L fuse
5 or
• 42 w/1000…1700 A Class L fuse
• 42 w/1000…2000 A CB
ND 600 100 42 65 or
• 100 w/850…1200 A Class L fuse
5 or
• 42 w/850…1500 A Class L fuse
• 42 w/900…1200 A CB
HD 450 100 30 65 or
• 100 w/650…800 A Class L fuse
5 or
• 30 w/650…1200 A Class L fuse
• 30 w/700…1200 A CB
21G…D740 LD 700 100 42 65 or
• 100 w/1000…1200 A Class L fuse
5 or
• 42 w/1000…1700 A Class L fuse
• 42 w/1000…2000 A CB
ND 650 100 42 65 or
• 100 w/900…1200 A Class L fuse
5 or
• 42 w/900…1600 A Class L fuse
• 42 w/900…2000 A CB
HD 500 100 30 65 or
• 100 w/750…800 A Class L fuse
5 or
• 30 w/750…1300 A Class L fuse
• 30 w/800…1200 A CB
continued on page 188
