Allen-Bradley PowerFlex 20-750-ENC-1

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 195
Power Wiring Chapter 4
Table 17 - 480V, 60 Hz Input - Code P3 Thermal Magnetic Circuit Breaker Options
Table 18 - 480V, 60 Hz Input - Code P5 Molded Case Disconnect Switch Options (Floor Mount Frame
8 Only)
Hp Amps Duty Line Side Terminal
Lugs
Terminal Size Recommended Torque
300 370 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
350 430 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
414 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
454 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
400 485 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
485 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
485 Heavy 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
450 545 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
545 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
545 Heavy 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
500 590 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
617 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
617 Heavy 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
600 710 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
710 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
650 765 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
740 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
700 800 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
Hp Amps Duty Line Side Terminal
Lugs
Terminal Size Recommended Torque
300 370 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
350 430 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
414 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
454 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
400 485 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
485 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
485 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
450 545 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
545 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
545 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
500 590 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
617 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
617 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
600 710 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
710 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
650 765 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
740 Normal 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
700 800 Light 140G-N-TLA43 (4) 4/0…500 MCM 43 N•m (381 lb•in)
