196 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 4 Power Wiring
Table 19 - 600V, 50 Hz Input - Code P3 Thermal Magnetic Circuit Breaker Options
Table 20 - 600V, 50 Hz Input - Code P5 Molded Case Disconnect Switch Options (Floor Mount Frame
8 Only)
Hp Amps Duty Line Side Terminal
Lugs
Terminal Size Recommended Torque
250 272 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
300 295 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
295 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
350 329 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
355 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
355 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
355 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
400 395 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
395 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
395 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
450 425 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
435 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
435 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
500 460 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
460 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
510 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
510 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
550 545 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
Hp Amps Duty Line Side Terminal
Lugs
Terminal Size Recommended Torque
250 272 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
300 295 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
295 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
350 329 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
355 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
355 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
355 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
400 395 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
395 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
395 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
450 425 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
435 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
435 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
500 460 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
460 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
510 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
510 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
550 545 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
