Rockwell Automation Publication 520-UM001A-EN-E - February 2013 103
Programming and Parameters Chapter 3
Advanced Program Group (continued)
A449 [Skip Freq Band 1] Related Parameter(s): A448, A450, A452, A454
A451 [Skip Freq Band 2]
A453 [Skip Freq Band 3]
A455 [Skip Freq Band 4]
Determines the band around A448
, A450, A452 and A454 [Skip Frequency x].
Values Default: 0.0 Hz
Min/Max: 0.0/30.0 Hz
Display: 0.1 Hz
Frequency
Time
Skip Frequency
Command
Frequency
Drive Output
Frequency
2x Skip
Frequency Band
A456 [PID 1 Trim Hi]
A468 [PID 2 Trim Hi]
Scales the upper value of the trim frequency when trim is active.
Values Default: 60.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
A457 [PID 1 Trim Lo]
A469 [PID 2 Trim Lo]
Scales the lower value of the trim frequency when trim is active.
Values Default: 0.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
