Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001A-EN-E - February 2013 129
Programming and Parameters Chapter 3
Parameter Name No. Parameter Name No. Parameter Name No.
EN Rx Overrruns 725 Fault 6 Current 646 HW Addr 2 688
EN Rx Packets 726 Fault 6 Freq 636 HW Addr 3 689
EN Subnet Act 1 697 Fault 6 Time-hr 616 HW Addr 4 690
EN Subnet Act 2 698 Fault 6 Time-min 626 HW Addr 5 691
EN Subnet Act 3 699 Fault 7 BusVolts 657 HW Addr 6 692
EN Subnet Act 4 700 Fault 7 Code 607 IR Voltage Drop 496
EN Subnet Cfg 1 133 Fault 7 Current 647 Jog Accel/Decel 432
EN Subnet Cfg 2 134 Fault 7 Freq 637 Jog Frequency 431
EN Subnet Cfg 3 135 Fault 7 Time-hr 617 Keypad Freq 426
EN Subnet Cfg 4 136 Fault 7 Time-min 627 Ki Speed Loop 538
EN Tx Errors 729 Fault 8 BusVolts 658 Kp Speed Loop 539
EN Tx Packets 728 Fault 8 Code 608 Language 30
Encoder Pos Tol 564 Fault 8 Current 648 Load Loss Level 490
Encoder PPR 536 Fault 8 Freq 638 Load Loss Time 491
Encoder Speed 378 Fault 8 Time-hr 618 Max Traverse 567
Encoder Speed F 379 Fault 8 Time-min 628 Maximum Freq 044
Energy Saved 023 Fault 9 BusVolts 659 Maximum Voltage 534
Enh Control Word 560 Fault 9 Code 609 Minimum Freq 043
Fault 1 BusVolts 651 Fault 9 Current 649 MOP Freq 427
Fault 1 Code 007 Fault 9 Freq 639 MOP Preload 429
Fault 1 Current 641 Fault 9 Time-hr 619 MOP Reset Sel 428
Fault 1 Freq 631 Fault 9 Time-min 629 MOP Time 430
Fault 1 Time-hr 611 Fault Clear 551 Motor Fdbk Type 535
Fault 1 Time-min 621 Fault10 BusVolts 660 Motor Lm 499
Fault 2 BusVolts 652 Fault10 Code 610 Motor Lx 500
Fault 2 Code 008 Fault10 Current 650 Motor NP FLA 034
Fault 2 Current 642 Fault10 Freq 640 Motor NP Hertz 032
Fault 2 Freq 632 Fault10 Time-hr 620 Motor NP Poles 035
Fault 2 Time-hr 612 Fault10 Time-min 630 Motor NP Power 037
Fault 2 Time-min 622 Fiber Status 390 Motor NP RPM 036
Fault 3 BusVolts 653 Find Home Dir 563 Motor NP Volts 031
Fault 3 Code 009 Find Home Freq 562 Motor OL Current 033
Fault 3 Current 643 Flux Current Ref 497 Motor OL Level 369
Fault 3 Freq 633 Flying Start En 545 Motor OL Ret 494
Fault 3 Time-hr 613 FlyStrt CurLimit 546 Motor OL Select 493
Fault 3 Time-min 623 Freq 1 510 Motor Rr 498
Fault 4 BusVolts 654 Freq 1 BW 511 MultiDrv Sel 169
Fault 4 Code 604 Freq 1 Ki 522 Opt Data In 1 161
Fault 4 Current 644 Freq 1 Kp 521 Opt Data In 2 162
Fault 4 Freq 634 Freq 2 512 Opt Data In 3 163
Fault 4 Time-hr 614 Freq 2 BW 513 Opt Data In 4 164
Fault 4 Time-min 624 Freq 2 Ki 524 Opt Data Out 1 165
Fault 5 BusVolts 655 Freq 2 Kp 523 Opt Data Out 2 166
Fault 5 Code 605 Freq 3 514 Opt Data Out 3 167
Fault 5 Current 645 Freq 3 BW 515 Opt Data Out 4 168
Fault 5 Freq 635 Freq 3 Ki 526 Opto Out Logic 075
Fault 5 Time-hr 615 Freq 3 Kp 525 Opto Out1 Level 070
Fault 5 Time-min 625 Half Bus Enable 549 Opto Out1 LevelF 071
Fault 6 BusVolts 656 Home Save 561 Opto Out1 Sel 069
Fault 6 Code 606 HW Addr 1 687 Opto Out2 Level 073

Allen-Bradley PowerFlex 525 Specifications

General

Horsepower	0.5-30 HP
kW	0.4-22 kW
Input Voltage	200-240V AC, 380-480V AC
Enclosure	IP20, NEMA/UL Type 1
Communications	EtherNet/IP
Control Methods	V/Hz, Sensorless Vector
STO	Safe Torque Off (STO)
Output Voltage	0-Input Voltage
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5-95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
