Rockwell Automation Publication 520-UM001A-EN-E - February 2013 147
Supplemental Drive Information Appendix A
Encoder Type: Incremental, dual channel
Supply: 12V, 250 mA.
Quadrature: 90 °, ±27 ° @ 25 °C.
Duty Cycle: 50%, +10%
Requirements: Encoders must be line driver type, quadrature (dual
channel) or pulse (single channel), 3.5...26V DC output,
single-ended or differential and capable of supplying a
minimum of 10 mA per channel. Allowable input is DC up to
a maximum frequency of 250 kHz. The encoder I/O
automatically scales to allow 5V, 12V and 24V DC nominal
voltages.
Control
Outputs
Relay: Quantity: (2) 1 Programmable Form A and 1 Programmable Form B
Specification
Resistive Rating:
Inductive Rating:
3.0 A @ 30V DC, 3.0 A @ 125V, 3.0 A @ 240V AC
0.5 A @ 30V DC, 0.5 A @ 125V, 0.5 A @ 240V AC
Opto: Quantity: (2) Programmable
Specification: 30V DC, 50 mA Non-inductive
Analog Quantity: (1) Non-Isolated 0-10V or 4-20 mA
Specification
Resolution:
0-10V DC Analog:
4-20 mA Analog:
10-bit
1 k ohm minimum
525 ohm maximum
PowerFlex 525 Estimated Watts Loss (Rated Load, Speed & PWM)
Voltage Output Current (A) Total Watts Loss
100...120V,
50/60 Hz 1-Phase
2.5 27.0
4.8 53.0
6.0 67.0
200...240V,
50/60 Hz 1-Phase
2.5 29.0
4.8 50.0
8.0 81.0
11.0 111.0
200...240V,
50/60 Hz 1-Phase
w/ EMC Filter
2.5 29.0
4.8 53.0
8.0 84.0
11.0 116.0
200...240V,
50/60 Hz 3-Phase
2.5 29.0
5.0 50.0
8.0 79.0
11.0 107.0
17.5 148.0
24.0 259.0
32.2 323.0
48.3 584.0
62.1 708.0
